| 牌号 | A1070P |
|---|---|
| 1070 | |
| 对应标准 | JIS H 4000-2022 铝及铝合金薄板、带材和板材 Aluminium and aluminium alloy sheets, strips and plates |
| 归类 | 铝及铝合金 |
| 标签 | 纯铝 |
| 说明 | • 纯铝，强度低，但具有优良的成形性、可焊性和耐腐蚀性。 • 用于反射板、照明灯具、装饰品、化工储罐、导电材料等。 • 本标准规定了轧制铝和铝合金薄板、带材、板、包覆板和盘的要求。 |
A1070P 化学元素成分含量(%)
| 成分 | Fe | Si | Mn | Cu | Ti | V | Al | Zn | Mg | 其他单个 |
|---|---|---|---|---|---|---|---|---|---|---|
| 最小值 | - | - | - | - | - | - | 99.7 | - | - | - |
| 值 | 0.25 | 0.2 | 0.03 | 0.04 | 0.03 | 0.05 | - | 0.04 | 0.03 | 0.03 |
A1070P 机械性能
| 厚度 t mm | 标记 | 热处理或状态 | 抗拉强度 σb Mpa | 屈服点 σs Mpa | 断后伸长率或延伸率 δ % |
|---|---|---|---|---|---|
| 4≤t≤6.5 | A1070P-H112 | H112 | ≥75 | ≥35 | ≥13 |
| 6.5＜t≤13 | ≥70 | ≥35 | ≥15 | ||
| 13＜t≤25 | ≥60 | ≥25 | ≥20 | ||
| 25＜t≤50 | ≥55 | ≥20 | ≥25 | ||
| 50＜t≤75 | ≥55 | ≥15 | ≥25 | ||
| 0.2≤t≤0.3 | A1070P-O | O | 55~95 | - | ≥15 |
| 0.3＜t≤0.5 | 55~95 | - | ≥20 | ||
| 0.5＜t≤0.8 | 55~95 | - | ≥25 | ||
| 0.8＜t≤1.3 | 55~95 | ≥15 | ≥30 | ||
| 1.3＜t≤13 | 55~95 | ≥15 | ≥35 | ||
| 13≤t≤50 | 55~95 | ≥15 | ≥30 | ||
| 0.2≤t≤0.3 | A1070P-H12 A1070P-H22 | H12 H22 | 70~110 | - | ≥2 |
| 0.3＜t≤0.5 | 70~110 | - | ≥3 | ||
| 0.5＜t≤0.8 | 70~110 | - | ≥4 | ||
| 0.8＜t≤1.3 | 70~110 | ≥55 | ≥6 | ||
| 1.3＜t≤2.9 | 70~110 | ≥55 | ≥8 | ||
| 2.9＜t≤12 | 70~110 | ≥55 | ≥9 | ||
| 0.2≤t≤0.3 | A1070P-H14 A1070P-H24 | H14 H24 | 85~120 | - | ≥1 |
| 0.3＜t≤0.5 | 85~120 | - | ≥2 | ||
| 0.5＜t≤0.8 | 85~120 | - | ≥3 | ||
| 0.8＜t≤1.3 | 85~120 | ≥65 | ≥4 | ||
| 1.3＜t≤2.9 | 85~120 | ≥65 | ≥5 | ||
| 2.9＜t≤12 | 85~120 | ≥65 | ≥6 | ||
| 0.2≤t≤0.5 | A1070P-H16 A1070P-H26 | H16 H26 | 100~135 | - | ≥1 |
| 0.5＜t≤0.8 | 100~135 | - | ≥2 | ||
| 0.8＜t≤1.3 | 100~135 | ≥75 | ≥3 | ||
| 1.3＜t≤4 | 100~135 | ≥75 | ≥4 | ||
| 0.2≤t≤0.5 | A1070P-H18 | H18 | ≥120 | - | ≥1 |
| 0.5＜t≤0.8 | ≥120 | - | ≥2 | ||
| 0.8＜t≤1.3 | ≥120 | - | ≥3 | ||
| 1.3＜t≤3 | ≥120 | - | ≥4 |
